Yaskawa SGMPH-04DAA6CD
The Yaskawa SGMPH-04DAA6CD is a rotary servo motor from the Sigma-II Series. With a nominal voltage rating of 400 V AC, this motor can deliver a continuous power output of 400 W, achieving a continuous torque of 1.27 N·m at its rated speed.
This Yaskawa SGMPH-04DAA6CD is supplied brand new by PartLogic for machine drive systems, motion control, equipment maintenance, replacement motor sourcing and industrial automation applications. It forms part of our Industrial automation > Motors > Servo motors range and is referenced internally as PartLogic SKU PL26805521639.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Type | Rotary Servo Motor (Sigma-II Series) |
| Product Line | SG Series |
| Part Number | SGMPH-04DAA6CD |
| Weight | 7.25 lbs (3.29 kg) |
| Nominal Supply Voltage | 400 V AC |
| Continuous Power Output | 400 W |
| Continuous Torque at Rated Speed | 1.27 N·m |
| Maximum Instantaneous Torque | 3.82 N·m |
| Base Speed | 3000 rpm |
| Maximum Operating Speed | 5000 rpm |
| Continuous Current (RMS) | 1.4 A |
| Short-Term Peak Current (RMS) | 4.4 A |
| Torque Sensitivity (per Amp) | 0.963 N·m/A |
| Rotor Inertia | 0.331 × 10⁻⁴ kg·m² |
| Permissible Load Inertia Multiplier | 7 × Rotor Inertia |
| Power-to-Inertia Ratio | 49.0 kW/s |
| Angular Acceleration Capacity | 38,500 rad/s² |
| Shaft Mechanical Interface | Keyed Shaft with Tapped Hole |
| Brand | Yaskawa |
