Yaskawa SGMJV-08A3A61
The Yaskawa SGMJV-08A3A61, part of the Sigma 5 series, is a capable servo motor with significant output performance. With a rated output of 800 watts, it operates efficiently at a voltage supply of 200 volts AC.
This Yaskawa SGMJV-08A3A61 is supplied brand new by PartLogic for machine drive systems, motion control, equipment maintenance, replacement motor sourcing and industrial automation applications. It forms part of our Industrial automation > Motors > Servo motors range and is referenced internally as PartLogic SKU PL26805425538.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Type | Servo motor |
| Product Line | Sigma 5 |
| Part Number | SGMJV-08A3A61 |
| Weight | 5.00 lbs (2.27 kg) |
| Rated Output | 800 Watts |
| Rated Power Supply Voltage | 200 Volts AC |
| Protection Class | IP65 |
| Rated Speed | 3,000 revolutions per minute (RPM) |
| Maximum Speed | 6,000 revolutions per minute (RPM) |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Rated Torque | 2.39 Newton-meter |
| Maximum Torque | 8.36 Newton-meter |
| Shaft Shape | Straight shaft with key and tap |
| Storage Temperature | -20 to 80°C (in a non-condensing environment) |
| Rated Current | 4.7 Amperes |
| Encoder Type | 20-bit absolute encoder |
| Mounting Method | Flange mount |
| Brand | Yaskawa |
