Yaskawa SGMAS-08ACA21
The Yaskawa SGMAS-08ACA21 is a robust motor from the Sigma III series, engineered for efficient operation. This unit supports a rated output of 750 watts and can achieve a rated speed of 3,000 RPM, going up to a maximum of 5,000 RPM. It operates effectively on a supply voltage of 200 Volts AC and has a current rating of 5.4 Amperes.
This Yaskawa SGMAS-08ACA21 is supplied brand new by PartLogic for machine drive systems, motion control, equipment maintenance, replacement motor sourcing and industrial automation applications. It forms part of our Industrial automation > Motors > Servo motors range and is referenced internally as PartLogic SKU PL26870225737.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Line | Sigma III |
| Part Number | SGMAS-08ACA21 |
| Weight | 12.00 lbs (5.44 kg) |
| Insulation Class | Class F |
| Rated Speed | 3,000 revolutions per minute (RPM) |
| Rated Output | 750 Watts |
| Maximum Speed | 5,000 revolutions per minute (RPM) |
| Rated Torque | 2.39 Newton-meter |
| Current Rating | 5.4 Amperes |
| Maximum Torque | 7.16 Newton-meter |
| Supply Voltage Class | 200 Volts AC |
| Type of Shaft End | Straight shaft without key |
| Supply Frequency | 50 to 60 Hertz |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Storage Temperature | -20 to 80°C (in a non-condensing environment) |
| Braking Unit | No brake |
| Humidity Tolerance | 20% to 80% relative humidity (without condensation) |
| Encoder Type | 17-bit incremental encoder |
| Brand | Yaskawa |
