Yaskawa SGDV-7R6A01A
The SGDV-7R6A01A from Yaskawa is a versatile drive within the Sigma 5 series. With an output rating of 1 kilowatt, it operates on a 3-phase input voltage of 200 to 230 Volts AC and accommodates an input frequency of 50 to 60 Hertz.
This Yaskawa SGDV-7R6A01A is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Servo drives range and is referenced internally as PartLogic SKU PL26862022830.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Line | Sigma 5 |
| Part Number | SGDV-7R6A01A |
| Weight | 5.00 lbs (2.27 kg) |
| Control Interface Type | Analog voltage and pulse train command |
| Input Frequency | 50 to 60 Hertz |
| Protection Rating | IP10 |
| Rated Output | 1 kilowatt |
| Input Voltage Rating | 200 Volts AC |
| Main Circuit Supply Voltage | 200 to 230 Volts AC |
| Resistor Type | Built-in or external regenerative resistor |
| Continuous Output Current Rating | 7.6 Amperes |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Storage Temperature | -20 to 85°C (in a non-condensing environment) |
| Instantaneous Output Current | 17 Amperes (maximum) |
| Communication Protocol | RS-422 communication port |
| Allowable Operating Range | 170 to 253 Volts AC |
| Input Phase Type | 3-phase input |
| Brand | Yaskawa |
