Yaskawa SGDG-01GTY21
The SGDG-01GTY21 is a servo amplifier from Yaskawa's SGDG series. Operating with an input voltage range of 90 to 253 VAC, this unit is a single-phase device designed for torque control applications.
This Yaskawa SGDG-01GTY21 is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Servo drives range and is referenced internally as PartLogic SKU PL26849653564.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Line | SGDG |
| Part Number | SGDG-01GTY21 |
| Weight | 1.38 lbs (0.62 kg) |
| Product Description | Servo Amplifier |
| Input Voltage | 90 to 253 VAC |
| Input Phase | Single-phase |
| Frequency Range | 50/60 Hz |
| Control Method | Torque control |
| Input Current per Channel | 2 A |
| Output Voltage | 0-253 V AC |
| Output Phase | 3-phase |
| Output Frequency | 0-300 Hz |
| Output Current | 0.91 A |
| Rated Power Output | 0.1 kW (0.13 HP) |
| Compatibility | 100 Watt servo motors |
| Mounting | Panel Mount |
| Brand | Yaskawa |
