Yaskawa CIMR-VU4A0005FAA
The Yaskawa CIMR-VU4A0005FAA belongs to the V1000 series of AC drives, designed for effective speed control in a variety of industrial applications. This 3-phase AC drive features an input voltage range of 380 to 480 volts and can output up to 3 horsepower in both normal-duty and heavy-duty scenarios, delivering output currents of 5.4 and 4.8 amps, respectively.
This Yaskawa CIMR-VU4A0005FAA is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives range and is referenced internally as PartLogic SKU PL26860302314.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Line | V1000 |
| Part Number | CIMR-VU4A0005FAA |
| Weight | 3.00 lbs (1.36 kg) |
| Product | AC Drive |
| Phase | 3-Phase |
| Input Voltage Rating | 380-480V AC |
| Normal-Duty Output Current | 5.4 Amps |
| Normal-Duty Output Power | 3 HP |
| Heavy-Duty Output Current | 4.8 Amps |
| Heavy-Duty Output Power | 3 HP |
| Enclosure | NEMA 1 |
| Output Voltage Rating | 0-480V AC |
| Mass | 1.9 kg |
| Operating Temperature | 0 to 40 degrees Celsius |
| Storage Temperature | 0 to 50 degrees Celsius |
| Maximum Operating Relative Humidity | 80%, non-condensing |
| Maximum Storage Relative Humidity | 80%, non-condensing |
| Maximum Operating Altitude | 1000m above sea level |
| Brand | Yaskawa |
