Yaskawa CIMR-VU2A0030FAA
The Yaskawa CIMR-VU2A0030FAA is a capable AC drive designed to manage three-phase systems at a line voltage of 200 volts. It is rated for both normal duty and heavy duty motor applications at 7.5 horsepower (Hp), providing flexible performance across various settings.
This Yaskawa CIMR-VU2A0030FAA is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives range and is referenced internally as PartLogic SKU PL26870066113.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Type | AC drive |
| Product Line | V1000 |
| Part Number | CIMR-VU2A0030FAA |
| Weight | 7.81 lbs (3.54 kg) |
| Series | AC Drives |
| Line Voltage | 200 Volts |
| Phase | 3 |
| ND Motor Rating | 7.5 Hp |
| HD Motor Rating | 7.5 Hp |
| ND Output Capacity | 11.4 kVA |
| HD Output Capacity | 9.5 kVA |
| ND Output Current | 30 Amps |
| HD Output Current | 25 Amps |
| Carrier Frequency | 2 to 15 kHz |
| Max. Output Frequency | 400 Hz |
| Installation Area | Indoors |
| Mounting | Vertical |
| Brand | Yaskawa |
