Yaskawa CDBR-4045D
The Yaskawa CDBR-4045D is a braking unit designed for operation at a voltage of 400V DC and a power capacity of 45 horsepower. This model supports a current of 18 amps and includes a brake chopper to enhance performance during dynamic braking events.
This Yaskawa CDBR-4045D is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Accessories > Braking units range and is referenced internally as PartLogic SKU PL26805327822.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Yaskawa |
| Product Line | Varispeed |
| Part Number | CDBR-4045D |
| Weight | 4.44 lbs (2.01 kg) |
| Voltage | 400V DC |
| Product | Braking Unit |
| Power Rating | 45 HP |
| Current | 18 Amps |
| Brake Chopper | Included |
| LED Indicators | Included |
| IP Rating | IP20 |
| Operating Temperature | 0 to 40 degrees Celsius |
| Relative Operating Humidity | Up to 80% (non-condensing) |
| Relative Storage Humidity | Up to 80% (non-condensing) |
| Maximum Altitude | 1000 meters above sea level |
| Storage Temperature | 0 to 50 degrees Celsius |
| Brand | Yaskawa |
