Telemecanique XS8-C40FP260
Discontinued by manufacturer 16,09,2021, proximity switch, 20mm sensing range, 24-240VAC, 50-60Hz, 5-500mA, 1 NO or 1 NC programmable, IP67, replaced by xs8c4a1mpg13
This Telemecanique XS8-C40FP260 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Proximity sensors > Inductive range and is referenced internally as PartLogic SKU PL26801734631.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Depth | 40 mm |
| Housing Material | Plastic |
| Length | 117 mm |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -25 °C |
| Mount | Flush |
| Operating Supply Voltage | 240 V |
| Ratings | IP67 |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Switching Current | 500 mA |
| Switching Frequency | 25 Hz |
| Termination | Screw |
| Width | 41 mm |
