Telemecanique XS7C40MP230
Discontinued by manufacturer, proximity sensor, inductive, 24-240VAC,dc, flush mount, 2-wire, 15mm sensing distance, 1 NO , 1 NC, screw clamp terminals, suggested replacement: xs7c4a1mpg13
This Telemecanique XS7C40MP230 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Proximity sensors > Inductive range and is referenced internally as PartLogic SKU PL26904360906.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Depth | 40 mm |
| Housing Material | Plastic |
| Length | 117 mm |
| Max Frequency | 50 Hz |
| Max Operating Temperature | 70 °C |
| Max Supply Voltage (DC) | 210 V |
| Min Operating Temperature | -25 °C |
| Min Supply Voltage (DC) | 24 V |
| Mount | Flush |
| Operating Supply Voltage | 210 V |
| Ratings | IP67 |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Sensing Distance | 15 mm |
| Sensing Method | Inductive |
| Termination | Screw |
| Width | 41 mm |
