Telemecanique LC1F330
The LC1F330 is a contactor manufactured by Schneider Electric as part of the TeSys series. It operates at a system voltage of up to 1000 V AC and is suitable for various utilization categories, including AC-1, AC-3, and AC-4. With a rated operational current of 400 A at temperatures below 40°C and 330 A at 55°C, this contactor is designed to handle substantial loads efficiently.
This Telemecanique LC1F330 is supplied brand new by PartLogic for switching, motor protection, starting, control panel builds, machinery maintenance and industrial electrical applications. It forms part of our Industrial automation > Motor control > Contactors range and is referenced internally as PartLogic SKU PL26805638113.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Type | Contactor |
| Product Line | TeSys |
| Part Number | LC1F330 |
| EAN | 3389110230895 |
| Weight | 19.00 lbs (8.62 kg) |
| System Voltage | Up to 1000 V AC 50/60 Hz, up to 460 V DC |
| Rated Operational Current | 400 A at \u003C40°C, 330 A at \u003C55°C |
| Utilization Category | AC-3, AC-4, AC-1 |
| Poles Description | 3P (3 NO) |
| Rated Impulse Withstand Voltage | 8 kV |
| Rated Insulation Voltage | 1000 V (IEC 60947-4-1), 1500 V (VDE 0110 group C) |
| Rated Breaking Capacity | 2640 A (IEC 60947-4-1) |
| Rated Short-Time Withstand Current | 2650 A at 40°C for 10 seconds |
| Associated Fuse Rating | 400 A aM at \u003C= 440 V, 500 A gG at \u003C= 440 V |
| Average Impedance | 0.28 mOhm at Ith 400 A 50 Hz |
| Power Dissipation per Pole | 44 W AC-1, 31 W AC-3 |
| Control Circuit Voltage Limits | 24-1000 V AC 40-400 Hz with LX1/LX9 coil, 24-460 V DC with LX4 coil |
| Operating Time | 40-65 ms closing, 100-170 ms opening with LX1/LX9 coil |
| Mounting Support | Plate |
| Brand | Schneider Electric |
