Siemens 6SE6440-2UC17-5AA1
The Siemens 6SE6440-2UC17-5AA1 is a reliable inverter in the MICROMASTER series. With a motor power capacity of 0.75 kW (1.0 HP), it functions efficiently within a specified 3-phase input voltage range of 200-240 V ± 10%.
This Siemens 6SE6440-2UC17-5AA1 is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Sinamics g110 range and is referenced internally as PartLogic SKU PL26801362464.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Siemens |
| Product Line | MICROMASTER |
| Part Number | 6SE6440-2UC17-5AA1 |
| UPC | 783087635265 |
| Weight | 5.00 lbs (2.27 kg) |
| Inverter Type | MICROMASTER 440 Inverter |
| Input Voltage Range | 3-phase, 200–240 V ± 10% |
| Motor Power Rating | 0.75 kW (1.0 HP) |
| Maximum Output Current | 3.9 A |
| Input Current | 2.9 A |
| Control Methods | Linear V/f, Quadratic V/f, Sensorless Vector, Flux Current Control, Energy Saving |
| Overload Capability | 150% for 60 seconds, 200% for 3 seconds |
| Operating Temperature Range | -10°C to +50°C |
| Humidity Tolerance | Up to 95%, non-condensing |
| Protection Features | Undervoltage, Overvoltage, Ground Faults, Motor Overtemperature, Inverter Overtemperature |
| EMC Compliance | Optional EMC filters, compliant with EN55011 Class A/B |
| Pulse Frequency | Adjustable: 2–16 kHz |
| Relay Outputs | 3 programmable relays: 30 V DC / 5 A, 250 V AC / 2 A |
| Braking Options | DC, compound, and dynamic braking |
| Serial Interface | RS-232 and RS-485 |
| Brand | Siemens |
