Siemens 6FC5203-0AF02-0AA2
The 6FC5203-0AF02-0AA2 model from Siemens, part of the SINUMERIK series, is engineered as a robust control interface. This device boasts a 12.1-inch TFT display with a resolution of 800 x 600 for clear visualization of operations.
This Siemens 6FC5203-0AF02-0AA2 is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Cnc systems > Hmi panels > Operator panels range and is referenced internally as PartLogic SKU PL26805665592.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Siemens |
| Product Line | SINUMERIK |
| Part Number | 6FC5203-0AF02-0AA2 |
| UPC | 804766297588 |
| Weight | 8.00 lbs (3.63 kg) |
| Humidity | 10% to 90% (non-condensing) |
| Power Supply | 24V DC |
| Mounting | Panel mount |
| Protection Class | IP65 (front), IP20 (rear) |
| Compliance | CE, UL, and RoHS |
| Color | RAL 7035 (light grey) |
| Display Size | 12.1 inches |
| Display Type | TFT (800 x 600 resolution) |
| Input Method | Membrane keys and touchpad |
| Backlight | LED |
| Interface | USB and Ethernet ports |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Brand | Siemens |
