Siemens 6ES7332-5HF00-0AB0
Siemens’ 6ES7332-5HF00-0AB0 is an Analog Output Module from the SIMATIC series designed for robust control applications. It features eight available outputs with multiple voltage and current ranges, making it versatile for various industrial tasks.
This Siemens 6ES7332-5HF00-0AB0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules range and is referenced internally as PartLogic SKU PL26801464906.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Rated value (DC) | 24 V |
| Reverse polarity protection | Yes |
| from load voltage L+ (without load), max. | 340 mA |
| from backplane bus 5 V DC, max. | 100 mA |
| Power loss, typ. | 6 W |
| Number of analog outputs | 8 |
| Voltage output, short-circuit protection | Yes |
| Voltage output, short-circuit current, max. | 25 mA |
| Current output, no-load voltage, max. | 18 V |
| 0 to 10 V | Yes |
| 1 V to 5 V | Yes |
| -10 V to +10 V | Yes |
| 0 to 20 mA | Yes |
| -20 mA to +20 mA | Yes |
| 4 mA to 20 mA | Yes |
| with voltage outputs, min. | 1 kΩ |
| with voltage outputs, capacitive load, max. | 1 µF |
| with current outputs, max. | 500 Ω |
| with current outputs, inductive load, max. | 10 mH |
| shielded, max. | 200 m |
| Resolution with overrange (bit including sign), max. | 12 bit; ±10 V, ±20 mA, 4 mA to 20 mA, 1 V to 5 V: 11 bit + sign; 0 V to 10 V, 0 mA to 20 mA: 12 bit |
| Conversion time (per channel) | 0.8 ms |
| for resistive load | 0.2 ms |
| for capacitive load | 3.3 ms |
| for inductive load | 0.5 ms; 0.5 ms (1 mH); 3.3 ms (10 mH) |
| Voltage, relative to output range, (+/-) | 0.5 %0.4 % |
| Current, relative to output range, (+/-) | 0.6 %0.5 % |
| Diagnostics function | Yes; Parameterizable |
| Diagnostic alarm | Yes; Parameterizable |
| Diagnostic information readable | Yes |
| Group error SF (red) | Yes |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Between the channels and load voltage L+ | Yes |
| between the channels and the power supply of the electronics | Yes |
| Isolation tested with | 500 V DC |
| required front connector | 40-pin |
| Width | 40 mm |
| Height | 125 mm |
| Depth | 117 mm |
| Weight, approx. | 272 g |
