Siemens 6ES72320HD220XA0
SIMATIC S7-200, Analog output EM 232, only for S7-22X CPU, 4 AI, +,-10 V DC, 0..20mA 12,11-bit converter
This Siemens 6ES72320HD220XA0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Compact plcs range and is referenced internally as PartLogic SKU PL27100589419.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| from external supply (24 V DC), max. | 70 mA |
| from backplane bus 5 V DC, max. | 20 mA |
| Power loss, typ. | 2 W |
| Number of analog outputs | 4 |
| -10 V to +10 V | Yes |
| 4 mA to 20 mA | Yes |
| with voltage outputs, min. | 5 kΩ |
| with current outputs, max. | 0.5 kΩ |
| Resolution with overrange (bit including sign), max. | 12 bit; U / 12 bit, I / 11 bit |
| for voltage output | 100 µs |
| for current output | 2 ms |
| bipolar signals | -32 000 to +32 000 |
| unipolar signals | 0 to 32 000 |
| Voltage, relative to output range, (+/-) | 2 %0.5 % |
| Current, relative to output range, (+/-) | 2 %0.5 % |
| Potential separation analog outputs | No |
| Plug-in I/O terminals | No |
| Width | 71.2 mm |
| Height | 80 mm |
| Depth | 62 mm |
| Weight, approx. | 190 g |
