Siemens 6ES72211BH220XA0
SIMATIC S7-200, DIGITAL INPUT EM 221, FOR S7-22X CPU ONLY, 16DI, 24V DC, SINK,SOURCE INPUT
This Siemens 6ES72211BH220XA0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Compact plcs range and is referenced internally as PartLogic SKU PL27100485665.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| from backplane bus 5 V DC, max. | 70 mA |
| Power loss, typ. | 3 W |
| Number of digital inputs | 16 |
| Sourcing/sinking input | Yes |
| Input characteristic curve in accordance with IEC 61131, type 1 | Yes |
| Type of input voltage | DC |
| Rated value (DC) | 24 V |
| for signal "0" | 0 to 5 V |
| for signal "1" | +15 to +30 V |
| for signal "1", typ. | 4 mA |
| — at "0" to "1", max. | 4.5 ms |
| shielded, max. | 500 m |
| unshielded, max. | 300 m |
| 2-wire sensor | Yes |
| — permissible quiescent current (2-wire sensor), max. | 1 mA |
| Potential separation digital inputs | Yes; Optocoupler |
| between the channels, in groups of | 4 |
| Isolation tested with | 500V AC for 1 minute |
| Plug-in I/O terminals | Yes |
| Width | 71.2 mm |
| Height | 80 mm |
| Depth | 62 mm |
| Weight, approx. | 160 g |
