Siemens 6ES7135-4FB01-0AB0
Siemens ET200S analog output module, 2AO.
This Siemens 6ES7135-4FB01-0AB0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL26801819107.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Isochronous mode | No |
| Rated value (DC) | 24 V; From power module |
| Reverse polarity protection | Yes |
| from load voltage L+ (without load), max. | 130 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, max. | 2 W |
| Address space per module, max. | 4 byte |
| Number of analog outputs | 2 |
| Voltage output, short-circuit protection | Yes |
| Voltage output, short-circuit current, max. | 25 mA |
| Cycle time (all channels) max. | 1.5 ms |
| 1 V to 5 V | Yes |
| -10 V to +10 V | Yes |
| for voltage output two-wire connection | Yes; Without compensation of the line resistances |
| for voltage output four-wire connection | Yes |
| with voltage outputs, min. | 1 kΩ |
| with voltage outputs, capacitive load, max. | 1 µF |
| Voltages at the outputs towards MANA | 15 V; max. 15 V continuous; 75 V for max. 1 s (mark to space ratio 1:20) |
| Current, max. | 50 mA; DC |
| shielded, max. | 200 m |
| Resolution with overrange (bit including sign), max. | 14 bit; 1 to 5 V: 12 bit, ±10 V: 13 bit + sign |
| for resistive load | 0.1 ms |
| for capacitive load | 0.5 ms |
| for inductive load | 0.5 ms |
| Voltage, relative to output range, (+/-) | 0.4 %0.2 % |
| Substitute values connectable | Yes; 0 to 65535 (range of values must be within the rated range) |
| Diagnostic information readable | Yes |
| Short-circuit | Yes |
| Group error | Yes |
| Group error SF (red) | Yes |
| Remark | 7 byte |
| Diagnostics short-circuit | Disable / enable |
| Group diagnostics | Disable / enable |
| Response to CPU/master STOP | Output current and de-energized/substitute a value/keep last value |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Between the channels and load voltage L+ | Yes |
| Isolation tested with | 500 V DC |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 40 g |
