Siemens 6ES71344GB110AB0
SIMATIC DP, Electronics module f. ET200S, 2AI Standard I-4DMU 15 mm width, +,-20mA; 13 bit+sign 4.. 20mA; 12-bit for 4-wire transmitter Cycle time 65 ms,channel with SF LED (group fault)
This Siemens 6ES71344GB110AB0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL27095833543.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Isochronous mode | No |
| Rated value (DC) | 24 V; From power module |
| from load voltage L+ (without load), max. | 30 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 0.6 W |
| Address space per module, max. | 4 byte |
| Number of analog inputs | 2 |
| permissible input current for current input (destruction limit), max. | 40 mA |
| Cycle time (all channels) max. | Number of active channels per module x basic conversion time |
| -20 mA to +20 mA | Yes; 50 Ohm |
| 4 mA to 20 mA | Yes; 50 Ohm |
| shielded, max. | 200 m |
| Measurement principle | integrating |
| Resolution with overrange (bit including sign), max. | 14 bit; ±20 mA: 14 bit, 4 to 20 mA: 13 bit |
| Integration time (ms) | 16,7 / 20 ms |
| Interference voltage suppression for interference frequency f1 in Hz | 50 / 60 Hz |
| Conversion time (per channel) | 65 ms; 55 / 65 ms |
| parameterizable | Yes; In four stages by means of digital filtering |
| Step: None | Yes; 1x cycle time |
| Step: low | Yes; 4x cycle time |
| Step: Medium | Yes; 32x cycle time |
| Step: High | Yes; 64x cycle time |
| Current, relative to input range, (+/-) | 0.6 %0.4 % |
| Wire-break | Yes; Measuring range 4 to 20 mA only |
| Group error | Yes |
| Overflow/underflow | YesDisable / enable |
| Group error SF (red) | Yes |
| Remark | 4 byte |
| Diagnostics wire break | Disable / enable (only in measuring range 4 to 20 mA) |
| Group diagnostics | Disable / enable |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Between the channels and load voltage L+ | No |
| Isolation tested with | 500 V DC |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 40 g |
