Siemens 6ES7134-4NB01-0AB0
The 6ES7134-4NB01-0AB0 is an analog input module from Siemens' SIMATIC series. This component supports two channels for thermocouple inputs and features a 15-bit signal resolution, ensuring precise temperature readings across varied applications.
This Siemens 6ES7134-4NB01-0AB0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL26805642817.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Rated value (DC) | 24 V; From power module |
| Reverse polarity protection | Yes |
| from load voltage L+ (without load), max. | 30 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 0.6 W |
| Address space per module, max. | 4 byte |
| Number of analog inputs | 2 |
| permissible input voltage for voltage input (destruction limit), max. | 20 V; ±20 V, continuous |
| Cycle time (all channels) max. | Number of active channels per module x basic conversion time |
| Technical unit for temperature measurement adjustable | Yes; Celsius / Fahrenheit |
| -80 mV to +80 mV | Yes |
| — Input resistance (-80 mV to +80 mV) | 1 MΩ |
| Type B | Yes |
| — Input resistance (Type B) | 1 MΩ |
| Type C | Yes |
| — Input resistance (Type C) | 1 MΩ |
| Type E | Yes |
| — Input resistance (Type E) | 1 MΩ |
| Type J | Yes |
| — Input resistance (type J) | 1 MΩ |
| Type K | Yes |
| — Input resistance (Type K) | 1 MΩ |
| Type L | Yes |
| — Input resistance (Type L) | 1 MΩ |
| Type N | Yes |
| — Input resistance (Type N) | 1 MΩ |
| Type R | Yes |
| — Input resistance (Type R) | 1 MΩ |
| Type S | Yes |
| — Input resistance (Type S) | 1 MΩ |
| Type T | Yes |
| — Input resistance (Type T) | 1 MΩ |
| — internal temperature compensation | Yes; possible with TM-E15S24-AT, TM-E15C24-AT |
| — external temperature compensation with compensations socket | Yes; one external compensating box per channel |
| parameterizable | YesYes; In four stages by means of digital filtering |
| — for thermocouples | Type B, C, E, J, K, L, N, R, S, T to IEC 584 |
| shielded, max. | 50 m |
| Measurement principle | integrating |
| Resolution with overrange (bit including sign), max. | 16 bit |
| Integration time (ms) | 16,7 / 20 ms |
| Interference voltage suppression for interference frequency f1 in Hz | 50 / 60 Hz |
| Conversion time (per channel) | 66 ms; 66 / 80 ms; additional conversion time for diagnostic wire break test |
| Step: None | Yes; 1x cycle time |
| Step: low | Yes; 4x cycle time |
| Step: Medium | Yes; 32x cycle time |
| Step: High | Yes; 64x cycle time |
| Voltage, relative to input range, (+/-) | 0.1 %; ±1.5 K for thermocouples, ±7 K for thermocouples type C, ±2.5 K with static thermal state (ambient temperature change < 0.3 K/min)0.05 %; ±1 K with thermocouples, ±5 K with thermocouples type C, ±1.5 K with static thermal state (ambient temperature change < 0.3 K/min) |
| Wire-break | Yes; only thermocouples |
| Group error | Yes |
| Overflow/underflow | YesDisable / enable |
| Group error SF (red) | Yes |
| Remark | 4 byte |
| Diagnostics wire break | Disable / enable (wire break is detected only in thermocouples) |
| Group diagnostics | Disable / enable |
| Comparison point | none / yes, internal |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Between the channels and load voltage L+ | Yes |
| Isolation tested with | 500 V DC |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 40 g |
