Siemens 6ES7134-4GD00-0AB0
Siemens 6ES71344GD000AB0 ET200S analogue input module, 4AI.
This Siemens 6ES7134-4GD00-0AB0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL26805565934.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Isochronous mode | No |
| Rated value (DC) | 24 V; From power module |
| Reverse polarity protection | Yes |
| from load voltage L+ (without load), max. | 125 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| present | Yes |
| short-circuit proof | Yes; approx. 200 mA for module |
| Power loss, typ. | 0.6 W |
| Address space per module, max. | 8 byte |
| Number of analog inputs | 4 |
| permissible input current for current input (destruction limit), max. | 30 mA; limited electronically |
| Cycle time (all channels) max. | 40 ms; 33 to 40 ms |
| 4 mA to 20 mA | Yes; Into 25 Ohm |
| shielded, max. | 200 m |
| Measurement principle | integrating |
| Resolution with overrange (bit including sign), max. | 13 bit; 4 to 20 mA: 13 bit |
| Integration time, parameterizable | Yes |
| Integration time (ms) | 16,67 / 20 ms |
| Interference voltage suppression for interference frequency f1 in Hz | 50 / 60 Hz |
| parameterizable | Yes; in 4 stages |
| Step: None | Yes; 1x cycle time |
| Step: low | Yes; 4x cycle time |
| Step: Medium | Yes; 16x cycle time |
| Step: High | Yes; 32x cycle time |
| Current, relative to input range, (+/-) | 0.4 %0.3 % |
| Wire-break | Yes; Measuring range 1 to 5 V only |
| Group error | Yes |
| Overflow/underflow | Yes1 |
| Group error SF (red) | Yes |
| Remark | 7 byte |
| Diagnostics wire break | 1 |
| Group diagnostics | 1 |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Between the channels and load voltage L+ | No |
| Isolation tested with | 500 V DC |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 40 g |
