Siemens 6ES71324BB310AB0
SIMATIC DP, 5 ELECTRON. MODULES FOR ET 200S, 2 DO HIGH FEATURE DC 24V,2A, 15 MM WIDTH DIAGNOSIS F. SHORT-CIRCUIT AND OPEN-CIRCUIT, FIRST-UP SIGNAL WITH LED SF (GROUP FAULT), 5 PIECES PER PACKAGING UNIT
This Siemens 6ES71324BB310AB0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL27095776015.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Reverse voltage protection | Yes; when using the same load voltage as on the power module |
| Rated value (DC) | 24 V; From power module |
| Reverse polarity protection | Yes; polarity reversal can lead to the digital outputs being connected through |
| from load voltage L+ (without load), max. | 5 mA; Per channel |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 1.4 W |
| Address space per module, max. | 1 byte |
| with packing | 2 bit |
| Type of digital output | Source output (PNP, current-sourcing) |
| Number of digital outputs | 2 |
| Short-circuit protection | Yes |
| Response threshold, typ. | 4 A |
| Limitation of inductive shutdown voltage to | -55 to -60 V, typ. L+( ) |
| Controlling a digital input | Yes |
| on lamp load, max. | 5 W10 Hz |
| lower limit | 12 Ω |
| upper limit | 3 400 Ω |
| for signal "1", min. | L+ (-1 V) |
| for signal "1" rated value | 2 A |
| for signal "1" permissible range, min. | 7 mA |
| for signal "1" permissible range, max. | 2.4 A |
| for signal "0" residual current, max. | 0.5 mA |
| "0" to "1", max. | 100 µs |
| "1" to "0", max. | 400 µs |
| for uprating | No |
| for redundant control of a load | Yes; per module |
| with resistive load, max. | 100 Hz |
| with inductive load, max. | 2 Hz; 0,5 H |
| Current per module, max. | 4 A |
| shielded, max. | 1 000 m |
| unshielded, max. | 600 m |
| Diagnostics function | Yes |
| Substitute values connectable | Yes; 0/1 |
| Diagnostic information readable | Yes |
| Wire-break | Yes; channel by channel |
| Short-circuit | Yes; channel by channel |
| Group error SF (red) | Yes |
| Status indicator digital output (green) | Yes |
| Remark | 3 byte |
| Diagnostics wire break | Disable / enable |
| Diagnostics short-circuit | Disable / enable |
| Response to CPU/master STOP | Substitute a value/keep last value |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Isolation tested with | 500 V DC |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 40 g |
