Siemens 6ES7132-4HB01-0AB0
Siemens ET200S remote I,O module, 2 relay outputs, 5A.
This Siemens 6ES7132-4HB01-0AB0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL26801718306.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Rated value (DC) | 24 V; From power module |
| Reverse polarity protection | Yes |
| from load voltage L+ (without load), max. | 30 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 0.6 W |
| Address space per module, max. | 1 byte |
| with packing | 2 bit |
| Type of digital output | Relays |
| Number of digital outputs | 2 |
| Short-circuit protection | No |
| Limitation of inductive shutdown voltage to | No |
| Controlling a digital input | Yes |
| for signal "1" rated value | 5 A |
| for signal "1" minimum load current | 8 mA |
| with resistive load, max. | 2 Hz |
| with inductive load, max. | 0.5 Hz |
| on lamp load, max. | 2 Hz |
| — Thermal continuous current, max. | 5 A |
| shielded, max. | 1 000 m |
| unshielded, max. | 600 m |
| Diagnostics function | No |
| Substitute values connectable | Yes; 0/1 |
| Status indicator digital output (green) | Yes |
| Response to CPU/master STOP | Substitute a value/keep last value |
| between the channels | Yes |
| between the channels and backplane bus | Yes |
| Between the channels and load voltage L+ | Yes |
| Ambient air temperature-barometric pressure-altitude | Tmin ... Tmax at 1 080 hPa ... 795 hPa (-1 000 m ... +2 000 m) // Tmin ... (Tmax - 10 K) at 795 hPa ... 658 hPa (+2 000 m ... +3 500 m) // Tmin ... (Tmax - 20 K) at 658 hPa ... 540 hPa (+3 500 m ... +5 000 m) |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 50 g |
