Siemens 6ES7131-4BF00-0AA0
The Siemens 6ES7131-4BF00-0AA0 is an electronics module designed for the ET 200S system. This module integrates 8 digital inputs and operates at a supply voltage of 24 V DC, facilitating effective signal processing in automated environments.
This Siemens 6ES7131-4BF00-0AA0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL26801721155.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Rated value (DC) | 24 V; From power module24 V |
| Reverse polarity protection | Yes |
| from supply voltage L+, max. | Dependent on encoder |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Number of outputs | 0; no encoder supply |
| Power loss, typ. | 1.2 W |
| Address space per module, max. | 1 byte |
| Number of digital inputs | 8 |
| Input characteristic curve in accordance with IEC 61131, type 1 | Yes; 2-wire sensors connectable |
| Type of input voltage | DC |
| for signal "0" | -30 to +5 V |
| for signal "1" | +15 to +30 V |
| for signal "1", typ. | 5 mA |
| — parameterizable | No |
| — at "0" to "1", min. | 2 ms |
| — at "0" to "1", max. | 4.5 ms |
| — at "1" to "0", min. | 2 ms |
| — at "1" to "0", max. | 4.5 ms |
| shielded, max. | 1 000 m |
| unshielded, max. | 600 m |
| 2-wire sensor | Yes |
| — permissible quiescent current (2-wire sensor), max. | 1.5 mA |
| Diagnostics function | No |
| Status indicator digital input (green) | Yes |
| Remark | 3-byte parameter (not accessible for the user) |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Isolation tested with | 500 V DC |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 35 g |
