Siemens 6ES7131-4BD01-0AA0
Siemens 6ES71314BD010AA0 ET200S digital input module, 4DI, 24VDC.
This Siemens 6ES7131-4BD01-0AA0 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Distributed io range and is referenced internally as PartLogic SKU PL26842986788.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Rated value (DC) | 24 V; From power module24 V |
| Reverse polarity protection | Yes |
| from supply voltage L+, max. | Dependent on encoder |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Type of output voltage | min. L+ (-0.5 V), under load |
| Rated value | 500 mA |
| permissible range, lower limit | 0 mA |
| permissible range, upper limit | 500 mA |
| Power loss, typ. | 0.7 W |
| Address space per module, max. | 1 byte |
| with packing | 4 bit |
| Number of digital inputs | 4 |
| Input characteristic curve in accordance with IEC 61131, type 1 | Yes |
| Type of input voltage | DC |
| for signal "0" | -30 to +5 V |
| for signal "1" | +15 to +30 V |
| for signal "1", typ. | 7 mA; at 24 V |
| — parameterizable | No |
| — at "0" to "1", min. | 2 ms; typically 3 ms |
| — at "0" to "1", max. | 4.5 ms |
| — at "1" to "0", min. | 2 ms; typically 3 ms |
| — at "1" to "0", max. | 4.5 ms |
| shielded, max. | 1 000 m |
| unshielded, max. | 600 m |
| 2-wire sensor | Yes |
| — permissible quiescent current (2-wire sensor), max. | 1.5 mA |
| Diagnostics function | No |
| Group error SF (red) | No |
| Status indicator digital input (green) | Yes; per channel |
| Remark | 1 byte |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Isolation tested with | 500 V DC |
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight, approx. | 35 g |
