Siemens 6AV6640-0AA00-0AX1
Mean Well GST120A12-R7B power supply, 12V, 8.5A, 102W.
This Siemens 6AV6640-0AA00-0AX1 is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Hmi > Touch panels range and is referenced internally as PartLogic SKU PL26801462526.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Product type designation | TD 400C |
| Design of display | STN, black/white |
| Screen diagonal | 3.7 in; 4-line |
| Number of lines | 4 |
| Number of characters per line | 24 |
| Character size | 5 mm |
| Horizontal image resolution | 192 pixel |
| Vertical image resolution | 64 pixel |
| MTBF backlighting (at 25 °C) | 20 000 h |
| Control elements | Membrane keyboard |
| System keys | Yes |
| — Number of configurable system keys | 15 |
| alphanumeric keyboard | No |
| Type of supply voltage | DC |
| MPI | Yes |
| AS-Interface | No |
| IP (at the front) | IP65 |
| IP (rear) | IP20 |
| NEMA (front) | NEMA 4, NEMA 4x, NEMA 12 (when installed) |
| Certificate of suitability | CE, FM Class I Div. 2, UL, C-TICK, NEMA 4, NEMA 4x, NEMA 12 |
| RCM (formerly C-TICK) | Yes |
| min. | 0 °C-20 °C |
| max. | 50 °C60 °C |
| Configuration tool | MicroWin (to be ordered separately) |
| Overall depth | 31 mm |
| Weight, approx. | 0.33 kg |
