Siemens 3VU1340-0MG00
This Siemens 3VU1340-0MG00 is supplied brand new by PartLogic for switching, motor protection, starting, control panel builds, machinery maintenance and industrial electrical applications. It forms part of our Industrial automation > Motor control > Circuit breakers range and is referenced internally as PartLogic SKU PL26805597259.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| protection class IP on the front | IP20 |
| reference code according to IEC 81346-2 | Q |
| continuous current rated value | 1.6 A |
| Substance Prohibitance (Date) | 03/01/2017 |
| Net Weight | 0.26 kg |
| ambient temperature during operation | -20 ... +55 °C |
| number of poles for main current circuit | 3 |
| adjustable current response value current of the current-dependent overload release | 1 ... 1.6 A |
| at 400 V rated value | 0.55 kW |
| type of voltage | AC/DC |
| number of NC contacts for auxiliary contacts instantaneous contact | 0 |
| number of NO contacts for auxiliary contacts instantaneous contact | 0 |
| number of CO contacts for auxiliary contacts | 0 |
| ground fault detection | No |
| phase failure detection | Yes |
| trip class | CLASS 10 |
| maximum short-circuit current breaking capacity (Icu) at 400 V rated value | 100 kA |
| design of the overcurrent release and short-circuit release | thermomagnetic |
| fastening method | screw and snap-on mounting onto 35 mm DIN rail according to DIN EN 50022 |
| height | 86 mm |
| width | 54 mm |
| depth | 70 mm |
| type of electrical connection for main current circuit | screw-type terminals |
| arrangement of electrical connectors for main current circuit | front side |
