Siemens 3TF2186-8BB4
Siemens 3TF2186-8BB4 contactor.
This Siemens 3TF2186-8BB4 is supplied brand new by PartLogic for switching, motor protection, starting, control panel builds, machinery maintenance and industrial electrical applications. It forms part of our Industrial automation > Motor control > Contactors range and is referenced internally as PartLogic SKU PL26805411556.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| product designation | Miniature contactor |
| product type designation | 3TF2 |
| size of contactor | 0 |
| reference code according to IEC 81346-2 | Q |
| Substance Prohibitance (Date) | 07/01/2006 |
| during operation | -25 ... +55 °C |
| number of poles for main current circuit | 6 |
| number of NO contacts for main contacts | 6 |
| number of NC contacts for main contacts | 0 |
| — at 400 V rated value | 9 A4 kW |
| at AC-4 at 400 V rated value | 2.6 A1 150 W |
| at AC-1 at 400 V rated value | 10 kW |
| type of voltage of the control supply voltage | DC |
| rated value | 24 V |
| control version of the switch operating mechanism | conventional |
| instantaneous contact | 20 |
| fastening method | screw fixing |
| side-by-side mounting | Yes |
| height | 48 mm |
| width | 90 mm |
| depth | 68 mm |
| for main current circuit | solder pin connectors |
| for auxiliary and control circuit | solder pin connectors |
