Siemens 3RQ00120DB40
This Siemens 3RQ00120DB40 is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805601621.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| product category | Plug-in relay |
| product designation | Coupling relay with plug-in relay |
| product type designation | 3RQ0 |
| display version LED | Yes |
| semi-conductor output | No |
| consumed active power | 0.9 W |
| insulation voltage for overvoltage category III according to IEC 60664 with degree of pollution 3 rated value | 250 V |
| surge voltage resistance rated value | 4 kV |
| shock resistance according to IEC 60068-2-27 | Sinusoidal half-wave 10g / 11 ms |
| vibration resistance according to IEC 60068-2-6 | 10 ... 150 Hz: 5 g |
| mechanical service life (operating cycles) typical | 20 000 000 |
| at AC-1 at 250 V typical | 200 000 |
| at AC-15 at 250 V typical | 100 000 |
| thermal current | 5 A |
| Net Weight | 35 g |
| control supply voltage at DC rated value | 24 V |
| initial value | 0.8 |
| full-scale value | 1.1 |
| operating range factor control supply voltage rated value at AC at 60 Hz initial value | 0.8 |
| at AC maximum | 20 ms |
| at DC maximum | 20 ms |
| OFF-delay time maximum | 20 ms |
| design of the switching function positively driven | No |
| product component plug-in socket | No |
| type of switching contact | 2 Changeover contacts |
| material of switching contacts | AgNi10 |
| at 250 V rated value | 3 A |
| at 30 V rated value | 3 A |
| contact reliability of auxiliary contacts | one incorrect switching operation of 100 million switching operations (DC 17 V, 5 mA) |
| type of voltage | DC |
| property of the output short-circuit proof | No |
| electromagnetic compatibility | acc. to IEC 61810-1 |
| display version as status display by LED | LED green |
| product function removable terminal | No |
| mounting position | any |
| fastening method | snap-on mounting |
| height | 36 mm |
| width | 21 mm |
| during operation | -40 ... +55 °C |
| during storage | -40 ... +85 °C |
| during transport | -40 ... +85 °C |
| relative humidity during operation | 5 ... 85 % |
