Siemens 3RH1122-1AB00
The Siemens 3RH1122-1AB00 is a contactor relay that operates with a control voltage of 24V AC. Designed for robustness, it features two normally-open and two normally-closed contacts, making it suitable for a wide range of applications.
This Siemens 3RH1122-1AB00 is supplied brand new by PartLogic for switching, motor protection, starting, control panel builds, machinery maintenance and industrial electrical applications. It forms part of our Industrial automation > Motor control > Contactors range and is referenced internally as PartLogic SKU PL26801734259.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Siemens |
| Product Type | Contactor Relay |
| Product Line | SIRIUS |
| Part Number | 3RH1122-1AB00 |
| UPC | 754554432342 |
| Weight | 0.19 lbs (0.09 kg) |
| Contact Configuration | 2 NO + 2 NC |
| Control Voltage | 24V AC, 50/60 Hz |
| Insulation Voltage | 690V, Pollution Degree 3 |
| Surge Voltage Rating | 6 kV |
| Protection Rating | IP20 (Front) |
| Shock Resistance | 10g (5 ms), 5g (10 ms) |
| Mechanical Lifespan | 30 million cycles |
| Max Current (AC-15, 230V) | 6A |
| Max Current (DC-13, 24V) | 10A |
| Short-Circuit Fuse | 10A gL/gG |
| Mounting Method | Screw or Snap-on |
| Operating Temperature | -25°C to +60°C |
| Brand | Siemens |
