Siemens 3NE3336
SITOR fuse link, with slotted blade contacts, NH2, In: 630 A, aR, Un AC: 1000 V, front indicator
This Siemens 3NE3336 is supplied brand new by PartLogic for control panels, machine wiring, power distribution, industrial maintenance and replacement applications. It forms part of our Industrial automation > Electrical distribution > Fuses range and is referenced internally as PartLogic SKU PL26801448015.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| product brand name | SENTRON |
| product designation | SITOR fuse link |
| design of the product | With slotted blade contacts |
| design of an identification indicator | front indicator |
| design of the switching contact | with slotted blade contacts for M10 screw fixing. mounting dimension: 110 mm. or for installation in LV HRC fuse bases or switch disconnectors |
| design of the fuse link | SITOR, LV HRC design |
| size of fuse system according to EN 60269-1 | NH2 |
| operating class of the fuse link | aR |
| varying load factor (WL) | 1 |
| type of voltage of the operating voltage | AC |
| operating voltage at AC according to UL rated value | 1 000 V |
| at AC | 1 000 V |
| according to IEC 60947-2 rated value | 100 kA |
| power loss [W] | 100 W |
| for rated value of the current at AC in hot operating state per pole | 100 W |
| maximum | 100 W50 °C |
| product description | with blade contacts, silver-plated |
| accessories included | no |
| mounting position | Any, preferably vertical |
| Net Weight | 801.2 g |
| minimum | -20 °C |
| environmental category | -20 to +50 at 95% relative humidity |
