Siemens 3NE3230-0B
Siemens 3NE3230-0B SITOR fuse link, 315A, 1000VAC, NH1 size.
This Siemens 3NE3230-0B is supplied brand new by PartLogic for control panels, machine wiring, power distribution, industrial maintenance and replacement applications. It forms part of our Industrial automation > Electrical distribution > Fuses range and is referenced internally as PartLogic SKU PL26801462162.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| product brand name | SENTRON |
| product designation | SITOR fuse link |
| design of the product | With slotted blade contacts |
| design of an identification indicator | front indicator |
| design of the switching contact | with slotted blade contacts for M10 screw fixing. mounting dimension: 110 mm. or for installation in LV HRC fuse bases or switch disconnectors |
| design of the fuse link | SITOR, LV HRC design |
| size of fuse system according to EN 60269-1 | NH1 |
| operating class of the fuse link | aR |
| varying load factor (WL) | 0.95 |
| type of voltage of the operating voltage | AC |
| operating voltage at AC according to UL rated value | 1 000 V |
| at AC | 1 000 V |
| according to IEC 60947-2 rated value | 100 kA |
| product description | with blade contacts, silver-plated |
| accessories included | no |
| mounting position | Any, preferably vertical |
| Net Weight | 580 g |
| minimum | -20 °C |
| maximum | 50 °C |
| environmental category | -20 to +50 at 95% relative humidity |
