SICK WT9-2P330
Discontinued by manufacturer, 1019026 - proximity bgs, pnp, red, 5.250mm range, sensing distance adj 4-pin m8
This SICK WT9-2P330 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric sensors range and is referenced internally as PartLogic SKU PL26801447968.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression |
| Dimensions (W x H x D) | 12 mm x 40 mm x 22 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 30 mm ... 250 mm 1) |
| Sensing range | 30 mm ... 250 mm 1) |
| Type of light | Visible red light |
| Light source | LED |
| Supply voltage | 10 V DC ... 30 V DC |
| Ripple | pp |
| Current consumption | 40 mA 1) |
| Switching output | PNP |
| Switching mode | Light/dark switching |
| Response time | ≤ 333 µs 2) |
| Connection type | Male connector M8, 4-pin |
| Housing material | Plastic, ABS |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP69K |
| Ambient operating temperature | –40 °C ... +60 °C |
| Ambient temperature, storage | –40 °C ... +75 °C |
| UL File No. | NRKH.E181493 & NRKH7.E181493 |
| eCl@ss 5.0 | 27270904 |
| eCl@ss 5.1.4 | 27270904 |
| eCl@ss 6.0 | 27270904 |
| eCl@ss 6.2 | 27270904 |
| eCl@ss 7.0 | 27270904 |
| eCl@ss 8.0 | 27270904 |
| eCl@ss 8.1 | 27270904 |
| eCl@ss 9.0 | 27270904 |
| eCl@ss 10.0 | 27270904 |
| eCl@ss 11.0 | 27270904 |
| ETIM 5.0 | EC002719 |
| ETIM 6.0 | EC002719 |
| ETIM 7.0 | EC002719 |
| UNSPSC 16.0901 | 39121528 |
| Phase Status | Phased Out |
