SICK WLL190T-2P434
Photoelectric sensor, fiber-optic, stand-alone, 0 to 2 m range, through-beam sensing, 10-24VDC, 2 pnp outputs, red led, light,dark switching, -25 to +55 degree c, IP66, (6032553)
This SICK WLL190T-2P434 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric sensors range and is referenced internally as PartLogic SKU PL26805624080.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Device type | Fiber-optic amplifier |
| Device type detail | Stand-alone |
| Dimensions (W x H x D) | 10.5 mm x 34.8 mm x 76.5 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 0 m ... 4 m (Through-beam system) 1) 2) |
| Sensing range | 0 mm ... 480 mm, Proximity system 3) 4) 0 m ... 2 m, Through-beam system 5) |
| Focus | Approx. 65° 6) |
| Type of light | Visible red light |
| Light source | LED 7) |
| Angle of dispersion | Approx. 65° 6) |
| Wave length | 650 nm |
| Adjustment | Menu-controlled Single teach-in button Cable |
| Indication | Display |
| Display | LED status display / 2x 4-character digital dual displays, Set value (green indicator) and actual value (red indicator) are displayed simultaneously, display of parameters |
| Supply voltage U B | 10 V DC ... 24 V DC 1) |
| Ripple | ≤ 10 % 2) |
| Current consumption | 50 mA |
| Switching output | PNP 3) 4) |
| Switching mode | Light/dark switching 3) 4) |
| Switching mode selector | Manually selectable |
| Response time | ≤ 2 ms, ≤ 60 µs, ≤ 250 µs |
| Switching frequency | 8,333 Hz, 2,000 Hz, 250 Hz |
| Time functions | Without time delay Off delay Switch-on delay One shot |
| Delay time | Programmable, 0 ms ... 9,999 ms |
| Connection type | Male connector M8, 4-pin |
| Circuit protection | A 5) B 6) C 7) D 8) |
| Protection class | III |
| Weight | 25 g |
| Special device | ✔ |
| Housing material | Plastic, ABS/PC |
| Enclosure rating | IP66 9) |
| Items supplied | LL3-TS15 fiber-optic cable, Cable, M8, 4-pin, 5 m |
| Ambient operating temperature | –25 °C ... +55 °C 10) |
| Ambient temperature, storage | –40 °C ... +70 °C |
| ECLASS 5.0 | 27270905 |
| ECLASS 5.1.4 | 27270905 |
| ECLASS 6.0 | 27270905 |
| ECLASS 6.2 | 27270905 |
| ECLASS 7.0 | 27270905 |
| ECLASS 8.0 | 27270905 |
| ECLASS 8.1 | 27270905 |
| ECLASS 9.0 | 27270905 |
| ECLASS 10.0 | 27270905 |
| ECLASS 11.0 | 27270905 |
| ECLASS 12.0 | 27270905 |
| ETIM 5.0 | EC002651 |
| ETIM 6.0 | EC002651 |
| ETIM 7.0 | EC002651 |
| ETIM 8.0 | EC002651 |
| UNSPSC 16.0901 | 39121528 |
| Phase Status | Active |
