SICK WLL180T-M432
(6039097), fiber-optic pe, pnp switching output, red led, cable out base unit,wll180t-m432, wll180t-m432 fiber, (6039097)
This SICK WLL180T-M432 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric sensors range and is referenced internally as PartLogic SKU PL26805599853.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Device type | Fiber-optic amplifier |
| Device type detail | Base unit |
| Functional principle detail | Depending on the optical fiber cable used |
| Sensing range max. | Depending on the optical fiber cable used |
| Light source | LED |
| Type of light | Visible red light |
| Normative reference | EN 62471:2008-09 | IEC 62471:2006, modified |
| LED risk group marking | Free group |
| Wave length | 650 nm |
| Average service life | 100,000 h at T a = +25 °C |
| Wire/pin | For deactivating the sender and executing the test logic/for setting the sensing range/synchronization with input signal |
| Display + operating buttons | For configuring the sensor parameters |
| LED yellow | Status of digital output Permanently on: Switching output active Permanently off: Digital output not active |
| Display | Display of sensor functions |
| Items supplied | BEF-WLL180 mounting bracket |
| MTTF D | 319 years |
| DC avg | 0 % |
| T M (mission time) | 20 years |
| Supply voltage U B | 12 V DC ... 24 V DC |
| Ripple | ≤ 10 % |
| Current consumption | ≤ 50 mA |
| Protection class | III |
| Number | 1 |
| Type | PNP |
| Switching mode | Light/dark switching |
| Switching mode selector | Manually selectable |
| Circuit protection outputs | Reverse polarity protected |
| Response time | ≤ 16 µs |
| Switching frequency | 31.2 kHz |
| Time functions | Without time delay, off delay, switch-on delay, ON and OFF delay, one shot |
| Delay time | Programmable, 0 ms ... 9,999 ms |
| Function of pin 4/black (BK) | Digital output, received light → Output Q1 HIGH |
| Function of pin 4/black (BK) – detail | The pin 4 function of the sensor can be configured |
| Function of pin 2/white (WH) | Teach-in input |
| Function of pin 2/white (WH) – detail | The pin 2 function of the sensor can be configured |
| Housing | Plastic, ABS/PC |
| Dimensions (W x H x D) | 10.5 mm x 34.6 mm x 71.9 mm |
| Connection | Cable, 4-wire |
| Deep-freeze property | Do not bend below 0 °C |
| Conductor size | 0.2 mm² |
| Length of cable (L) | 2 m |
| Cable | Plastic, PVC |
| Weight | 25 g |
| Enclosure rating | IP50 (EN 60529) |
| Ambient operating temperature | –25 °C ... +55 °C |
| Ambient temperature, storage | –40 °C ... +70 °C |
| Typ. Ambient light immunity | Artificial light: ≤ 3,000 lx Sunlight: ≤ 10,000 lx |
| Shock resistance | 50 g, 11 ms (3 positive and 3 negative shocks along X, Y, Z axes, 18 total shocks (EN60068-2-27)) |
| Vibration resistance | 10 Hz ... 55 Hz (Amplitude 1 mm, 3 x 30 min (EN60068-2-6)) |
| Air humidity | 35 % ... 85 %, relative humidity (no condensation) |
| Electromagnetic compatibility (EMC) | EN 60947-5-2 |
| UL File No. | NRKH.E300503 |
| RoHS certificate | ✔ |
| Timer function | Deactivated Switch-on delay Off delay ON and OFF delay Impulse (one shot) Switch-on delay and pulse |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| ACMA declaration of conformity | ✔ |
| Moroccan declaration of conformity | ✔ |
| China RoHS | ✔ |
| ULus approval | ✔ |
| Photobiological safety (DIN EN 62471) certificate | ✔ |
| Information according to Art. 3 of Data Act (Regulation EU 2023/2854) | ✔ |
| ECLASS 5.0 | 27270905 |
| ECLASS 5.1.4 | 27270905 |
| ECLASS 6.0 | 27270905 |
| ECLASS 6.2 | 27270905 |
| ECLASS 7.0 | 27270905 |
| ECLASS 8.0 | 27270905 |
| ECLASS 8.1 | 27270905 |
| ECLASS 9.0 | 27270905 |
| ECLASS 10.0 | 27270905 |
| ECLASS 11.0 | 27270905 |
| ECLASS 12.0 | 27270905 |
| ETIM 5.0 | EC002651 |
| ETIM 6.0 | EC002651 |
| ETIM 7.0 | EC002651 |
| ETIM 8.0 | EC002651 |
| UNSPSC 16.0901 | 39121528 |
