SICK WLL170-2P330
Discontinued by manufacturer, photoelectric sensor, fiber optic, through beam and proximity systems, with red led, 0-4000mm sensing range, 10-30VDC, pnp light,dark switching, 3 pin m8 connector, 6029513
This SICK WLL170-2P330 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric sensors range and is referenced internally as PartLogic SKU PL26805675851.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Device type | Fiber-optic amplifier |
| Dimensions (W x H x D) | 10.5 mm x 35.5 mm x 83.7 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 0 mm ... 4,000 mm (Through-beam system) 1) |
| Sensing range | 0 mm ... 160 mm, Proximity system 2) 3) 0 mm ... 700 mm, Through-beam system 4) |
| Focus | Approx. 65° 5) |
| Type of light | Visible red light |
| Light source | LED 6) |
| Angle of dispersion | Approx. 65° 5) |
| Wave length | 660 nm |
| Adjustment | Potentiometer, 10 turns |
| Indication | LED |
| Supply voltage U B | 10 V DC ... 30 V DC 1) |
| Ripple | 10 % 2) |
| Current consumption | 30 mA 3) |
| Switching output | PNP |
| Number of switching outputs | 1 |
| Switching mode | Light/dark switching |
| Switching mode selector | Selectable via light/dark selector |
| Response time | ≤ 250 µs 4) |
| Switching frequency | 2,000 Hz 5) |
| Time functions | Off delay |
| Delay time | Selectable by sliding switch, ≤ 40 ms |
| Input | - |
| Connection type | Connector M8, 3-pin |
| Circuit protection | A 6) B 7) C 8) D 9) |
| Protection class | III |
| Weight | 70 g |
| Housing material | Plastic, ABS/PC |
| Enclosure rating | IP66 10) |
| Items supplied | BEF-WLL170 mounting bracket |
| Ambient operating temperature | –25 °C ... +55 °C |
| Ambient temperature, storage | –40 °C ... +70 °C |
| UL File No. | NRKH.E300503 & NRKH7.E300503 |
| MTTF D | 836 years |
| DC avg | 0 % |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| ACMA declaration of conformity | ✔ |
| China RoHS | ✔ |
| cULus certificate | ✔ |
| Photobiological safety (DIN EN 62471) certificate | ✔ |
| ECLASS 5.0 | 27270905 |
| ECLASS 5.1.4 | 27270905 |
| ECLASS 6.0 | 27270905 |
| ECLASS 6.2 | 27270905 |
| ECLASS 7.0 | 27270905 |
| ECLASS 8.0 | 27270905 |
| ECLASS 8.1 | 27270905 |
| ECLASS 9.0 | 27270905 |
| ECLASS 10.0 | 27270905 |
| ECLASS 11.0 | 27270905 |
| ECLASS 12.0 | 27270905 |
| ETIM 5.0 | EC002651 |
| ETIM 6.0 | EC002651 |
| ETIM 7.0 | EC002651 |
| ETIM 8.0 | EC002651 |
| UNSPSC 16.0901 | 39121528 |
| Phase Status | Phased Out |
