SICK WLG12-P537
Photoelectric retro reflective sensor, 6-12.5mm parallel beam, 8-beams, 87.5mm detection height, 18-30VDC, 100mA, 650nm wavelength, 2x pnp, m12 male 5 pin connection, led indicator, -25 to +55 degrees c, IP57, (1015798)
This SICK WLG12-P537 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric sensors range and is referenced internally as PartLogic SKU PL26805602129.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Sensor principle | Photoelectric retro-reflective sensor |
| Minimum detectable object (MDO) | Parallel beam, 6 mm ... 12.5 mm |
| Beam separation | 12.5 mm |
| Number of beams | 8 |
| Detection height | 87.5 mm |
| Resolution (adjustable) | 6 mm ... 12.5 mm |
| Wave length | 650 nm |
| Supply voltage V s | DC 18 V ... 30 V |
| Power consumption sender | 80 mA |
| Ripple | pp |
| Output current I max. | ≤ 100 mA |
| Output load, capacitive | 100 nF |
| Output load, Inductive | 1 H |
| Initialization time | 0.6 s |
| Switching output | 2 x PNP |
| Output mode | Q dark switching |
| Teach-in input | PNP |
| Dimensions (W x H x D) | 62 mm x 106 mm x 46.6 mm |
| Connection type | Plug, M12, 5-pin |
| Housing material | Plastic |
| Display | LED |
| Enclosure rating | IP67 |
| Circuit protection | U V connections, reverse polarity protected Output Q short-circuit protected Interference pulse suppression |
| Protection class | II |
| Weight | 230 g |
| Front screen | PMMA |
| Maximum range | 1.5 m |
| Minimum range | ≥ 100 mm |
| Operating range | 1.5 m |
| Response time | Parallel beam, 0.6 ms |
| Shock resistance | 10 g / DIN EN 60068-2-29 / 16 ms |
| Vibration resistance | 5 g, 10 Hz ... 55 Hz (IEC 68-2-6) |
| EMC | EN 60947-5-2 |
| Ambient operating temperature | –25 °C ... +55 °C |
| Ambient temperature, storage | –20 °C ... +70 °C |
| ECLASS 5.0 | 27270910 |
| ECLASS 5.1.4 | 27270910 |
| ECLASS 6.0 | 27270910 |
| ECLASS 6.2 | 27270910 |
| ECLASS 7.0 | 27270910 |
| ECLASS 8.0 | 27270910 |
| ECLASS 8.1 | 27270910 |
| ECLASS 9.0 | 27270910 |
| ECLASS 10.0 | 27270910 |
| ECLASS 11.0 | 27270910 |
| ECLASS 12.0 | 27270910 |
| ETIM 5.0 | EC002549 |
| ETIM 6.0 | EC002549 |
| ETIM 7.0 | EC002549 |
| ETIM 8.0 | EC002549 |
| UNSPSC 16.0901 | 39121528 |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| ACMA declaration of conformity | ✔ |
| Moroccan declaration of conformity | ✔ |
| China RoHS | ✔ |
