SICK DT50-P1123
Mid range distance sensor, w, background suppression, 10-30VDC, 4-20mA, 2.1W, m12 5 pin male connector, laser light, 30 to +65 degree c, IP65, 1047118
This SICK DT50-P1123 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Distance sensors > Laser distance range and is referenced internally as PartLogic SKU PL26801355318.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Measuring range | 200 mm ... 10,000 mm, 90% remission factor 200 mm ... 5,000 mm, 18% reflection factor 200 mm ... 2,500 mm, 6% remission factor |
| Target | Natural objects |
| Resolution | 1,000 µm |
| Repeatability | ≥ 2.5 mm |
| Measurement accuracy | ± 10 mm |
| Response time | 20 ms ... 30 ms, 20 ms / 30 ms |
| Output time | ≥ 4 ms |
| Light source | Laser, red |
| Type of light | Visible red light |
| Typ. light spot size (distance) | 15 mm x 15 mm (10 m) |
| Normative reference | IEC 60825-1:2014, EN 60825-1:2014 |
| Laser class | 1 |
| Average laser service life (at 25 °C) | 100,000 h |
| Additional function | Set moving average: fast/slow Switching mode: distance to object (DtO) Teach-in, scaling and inversion of digital output Set hysteresis Teach-in, scaling and inversion of analog output Multifunctional input: laser off / external teach / deactivated Switch-off display Reset to factory default Lock user interface |
| MTTF D | 101 years |
| DC avg | 0% |
| Number | 1 |
| Type | Current output |
| Maximum output current I A | ≤ 100 mA |
| Current | 4 mA ... 20 mA, ≤ 300 Ω |
| Multifunctional input (MF) | 1 x |
| Hysteresis | 10 mm ... 1,000 mm |
| Supply voltage U B | DC 10 V ... 30 V |
| Power consumption | ≤ 2.1 W |
| Ripple | ≤ 5 V pp |
| Initialization time | ≤ 250 ms |
| Warm-up time | ≤ 15 min |
| Display | LC display, 2 x LED |
| Enclosure rating | IP65 |
| Protection class | III |
| Dimensions (W x H x D) | 36.1 mm x 62.7 mm x 57.7 mm |
| Housing material | Metal (zinc diecast) |
| Window material | Plastic (PMMA) |
| Weight | 200 g |
| Ambient temperature, operation | –30 °C ... +65 °C –30 °C ... +80 °C, operation with 2 cooling plates –30 °C ... +140 °C, operation with 2 cooling plates and protection filter |
| Ambient temperature, storage | –40 °C ... +75 °C |
| Max. rel. humidity (not condensing) | ≤ 95 % |
| Typ. Ambient light immunity | 40,000 lx |
| Vibration resistance | EN 60068-2-6, EN 60068-2-64 |
| Shock resistance | EN 60068-2-27 |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| ACMA declaration of conformity | ✔ |
| Moroccan declaration of conformity | ✔ |
| China RoHS | ✔ |
| cULus certificate | ✔ |
| ECLASS 5.0 | 27270801 |
| ECLASS 5.1.4 | 27270801 |
| ECLASS 6.0 | 27270801 |
| ECLASS 6.2 | 27270801 |
| ECLASS 7.0 | 27270801 |
| ECLASS 8.0 | 27270801 |
| ECLASS 8.1 | 27270801 |
| ECLASS 9.0 | 27270801 |
| ECLASS 10.0 | 27270801 |
| ECLASS 11.0 | 27270801 |
| ECLASS 12.0 | 27270916 |
| ETIM 5.0 | EC001825 |
| ETIM 6.0 | EC001825 |
| ETIM 7.0 | EC001825 |
| ETIM 8.0 | EC001825 |
| UNSPSC 16.0901 | 41111613 |
