Semikron SKN130,12
160A 1200v do-8 m12 anode to case , bulk
This Semikron SKN130/12 is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Power electronics > Diode modules range and is referenced internally as PartLogic SKU PL26805608963.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Element Configuration | Single |
| Forward Current | 165 A |
| Forward Voltage | 1.5 V |
| Height | 27.7 mm |
| Length | 27.7 mm |
| Max Forward Surge Current (Ifsm) | 2.5 kA |
| Max Operating Temperature | 180 °C |
| Max Repetitive Reverse Voltage (Vrrm) | 1.2 kV |
| Max Surge Current | 2.5 kA |
| Min Operating Temperature | -40 °C |
| Mount | Stud |
| Number of Pins | 2 |
| Peak Non-Repetitive Surge Current | 2.5 kA |
| Peak Reverse Current | 22 mA |
| REACH SVHC | No |
| RoHS | Compliant |
| Width | 24 mm |
