Semikron SKD60,08
Bridge Rectifier Diode, 3-Phase, 92A, 800V, Module
This Semikron SKD60/08 is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Power electronics > Diode modules range and is referenced internally as PartLogic SKU PL26805605743.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Case/Package | Module |
| Element Configuration | Single |
| Forward Voltage | 1.6 V |
| Height | 34 mm |
| Hole Diameter | 5.3 mm |
| Length | 65 mm |
| Max Forward Surge Current (Ifsm) | 1 kA |
| Max Operating Temperature | 125 °C |
| Max Output Current | 92 A |
| Max Repetitive Reverse Voltage (Vrrm) | 800 V |
| Min Operating Temperature | -40 °C |
| Mount | Panel, Screw |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Peak Non-Repetitive Surge Current | 1 kA |
| Peak Reverse Current | 500 µA |
| REACH SVHC | No |
| RoHS | Compliant |
| Termination | Screw |
| Width | 48 mm |
