Schneider Electric TSXPSY2600
The TSXPSY2600 from Schneider Electric is a power supply module designed for versatile applications. This unit operates at primary voltage ratings of 100 or 240 V AC while providing secondary outputs of 24 V DC and 5 V DC at 15 W and 25 W respectively.
This Schneider Electric TSXPSY2600 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Power supplies range and is referenced internally as PartLogic SKU PL26909214024.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Brand | Telemecanique |
| Manufacturer Part Number | TSXPSY2600 |
| Product Type | Power Supply Module |
| Primary Voltage | 100–240 V AC |
| Network Frequency | 50/60 Hz (47–63 Hz limits) |
| Input Current | 300 mA @ 240 V, 500 mA @ 100 V |
| Inrush Current | 37 A @ 100 V, 75 A @ 240 V |
| Secondary Outputs | 24 V DC (15 W), 5 V DC (25 W) |
| Total Useful Secondary Power | 26 W |
| Insulation Resistance | ≥ 100 MΩ primary/secondary |
| Protection | Overload, short-circuit, overvoltage on secondary outputs |
| Internal Fuse | 4 A time-delayed |
| LED Indicators | Green voltages OK, green 24 V sensor, red battery fault |
| Operating Temperature | 0–60 °C (32–140 °F) |
| Storage Temperature | -25–70 °C (-13–158 °F) |
| Relative Humidity | 10–95% operating, 5–95% storage, non-condensing |
| Altitude | 0–2000 m (0–6561.68 ft) |
| Protection Class | IP20 |
| Pollution Degree | 2 |
| Weight | 0.51 kg (1.12 lb approx) |
| Standards and Certifications | CSA C22.2 No.142, 213; IEC 61131-2; UL 508; CE; marine certifications (RMRS, BV, RINA, GL, ABS, DNV, LR) |
