Schneider Electric TSXETZ410
The TSXETZ410 from Schneider Electric serves as a micro ethernet module, functioning within the Modicon series. It supports transmission rates of 10,100 Mbps for Ethernet connections, while modem links achieve up to 56 kbps.
This Schneider Electric TSXETZ410 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Communication modules > Ethernet range and is referenced internally as PartLogic SKU PL26928301323.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Type | Micro Ethernet Module |
| Product Line | Modicon |
| Part Number | TSXETZ410 |
| EAN | 3595862042802 |
| Weight | 0.94 lbs (0.43 kg) |
| Transmission Rate | 10/100 Mbps for Ethernet; 56 kbps maximum for serial link by modem |
| Topology | Star Ethernet, Tree-structure Ethernet |
| Supply Voltage | 24 V DC |
| Current Consumption | 100 mA at 24 V DC; 50 mA to 200 mA at 24 V DC |
| Power Dissipation | 2.4 W to 4 W |
| Physical Interface | RS232 serial link by modem, Ethernet |
| Cable Length | Max. 100 m between terminal device and hubs by Ethernet |
| Standards Compliance | UL 508, IEC 1000-4-2 level 3, IEC 1000-4-3 level 3, IEC 1000-4-4 level 3, IEC 1000-4-5, ANSI/IEEE Std 802.3, ISO/IEC 8802-3, IEC 61131-2 |
| Connector Types | Screw terminal block, mini DIN for terminal port, RJ45, 9-way SUB-D connectors |
| Mounting Support | Mounting plate |
| Communication Protocols | Ethernet, RS232 serial link by modem |
| Maximum Simultaneous Connections | 8 standard browsers |
| Brand | Schneider Electric |
