Schneider Electric TSXETY5103
The Schneider Electric TSXETY5103 is an Ethernet TCP,IP module for Modicon systems. Capable of data transmission at 10 or 100 Mbit,s, this module offers a variety of communication services, allowing efficient integration into control setups.
This Schneider Electric TSXETY5103 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Communication modules > Ethernet range and is referenced internally as PartLogic SKU PL26895672012.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Premium Automation platform |
| Product or component type | Ethernet TCP/IP module |
| Physical interface | RJ45 - 10BASE-T/100BASE-TX 1 twisted pair |
| Transmission rate | 10/100 Mbit/s |
| Communication service | Bandwidth management | FDR server | Global Data | I/O scanning | Modbus TCP messaging | NTP time synchronization | Optional TCP open | SMTP e-mail notification | SNMP agent | Uni-TE messaging | SOAP XML Web (server) |
| Supply | Via the power supply of the rack |
| Local signalling | 1 LED for collision detection (COL) | 1 LED for Ethernet network status (RUN) | 1 LED for Ethernet port fault (ERR) | 1 LED for transmission/reception activity (TX/TR) |
| Communication port protocol | Modbus TCP | Uni-Telway |
| Maximum number of connections | 64 |
| Web server | Transparent ready class C30 |
| web feature | FactoryCast configurable | Rack viewer | Data Editor (via PC terminal) |
| Memory description | User web page size 8 MB |
| Marking | CE |
| Product compatibility | PL7 Pro | Unity Pro |
| Current consumption | 530 mA 5 V DC |
| Module format | Standard |
| Net weight | 0.34 kg |
| Standards | FM Class 1 Division 2 group D | FM Class 1 Division 2 group B | EN 61131-2 | FM Class 1 Division 2 group A | UL 508 | CSA 1010-1 | FM Class 1 Division 2 group C |
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0…60 °C |
| Relative humidity | 10…95 % at 60 °C without condensation |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.5 cm |
| Package 1 Width | 18.0 cm |
| Package 1 Length | 26.0 cm |
| Package 1 Weight | 450.0 g |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 40.0 cm |
| Package 2 Length | 60.0 cm |
| Package 2 Weight | 6.347 kg |
