Schneider Electric TSXETY210
The TSXETY210 module from Schneider Electric is an Ethernet TCP,IP module designed for Modicon applications. It operates at a transmission rate of 10 Mbit,s and features a maximum of 64 connections, allowing multiple devices to communicate simultaneously.
This Schneider Electric TSXETY210 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Communication modules > Ethernet range and is referenced internally as PartLogic SKU PL26928294214.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Premium Automation platform |
| Product or component type | Ethernet TCP/IP module |
| Automation architecture | Premium Warm Standby |
| Physical interface | AUI - 100BASE-5 1 AUI cable | RJ45 - 10BASE-T 1 twisted pair |
| Transmission rate | 10 Mbit/s |
| Communication service | Modbus TCP messaging | SNMP agent | Uni-TE messaging | Common words, Ethway/X-Way |
| Supply | Via the power supply of the rack |
| Local signalling | 1 LED for collision detection (COL) | 1 LED for Ethernet network status (RUN) | 1 LED for Ethernet port fault (ERR) | 1 LED for transmission/reception activity (TX/TR) |
| Communication port protocol | Modbus TCP | Ethway/X-Way | Uni-Telway |
| Maximum number of connections | 64 |
| Web server | Transparent ready class A10 |
| Marking | CE |
| Product compatibility | PL7 Pro | Unity Pro |
| Current consumption | 1200 mA 5 V DC with remote power supply (AUI) | 800 mA 5 V DC without remote power supply (RJ45) |
| Module format | Standard |
| Net weight | 0.34 kg |
| Standards | FM Class 1 Division 2 group C | FM Class 1 Division 2 group A | FM Class 1 Division 2 group B | FM Class 1 Division 2 group D | EN 61131-2 |
| Product certifications | UL 508 | CSA 1010-1 |
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0…60 °C |
| Relative humidity | 10…95 % at 60 °C without condensation |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.5 cm |
| Package 1 Width | 18.0 cm |
| Package 1 Length | 26.0 cm |
| Package 1 Weight | 484.0 g |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 40.0 cm |
| Package 2 Length | 60.0 cm |
| Package 2 Weight | 6.755 kg |
