Schneider Electric TSXDSY08R5
The Schneider Electric TSXDSY08R5 is a discrete output module designed for efficient control applications. It features eight relay outputs and accommodates both DC and AC voltage ranges, making it versatile for various setups.
This Schneider Electric TSXDSY08R5 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26928292697.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Premium Automation platform |
| Product or component type | Discrete output module |
| Discrete output number | 8 |
| Discrete output type | Relay not protected |
| Discrete output voltage | 12...24 V DC conforming to EN/IEC 61131-2 10...34 V | 24...240 V AC conforming to EN/IEC 61131-2 20...264 V |
| [Ith] conventional free air thermal current | 3 A |
| Response time | < 10 ms (deactivation) | < 8 ms (activation) |
| Contacts type and composition | 1 NO |
| Output overvoltage protection | DC inductive, by discharge diode on each preactuator | AC inductive, by RC circuit MOV (ZNO) on each preactuator |
| Output overload protection | 1 external fuse per channel or group of channel fast blow |
| Short-circuit protection | 1 external fuse per channel or group of channel fast blow |
| isalotion resistance | > 10 MOhm 500 V |
| Power dissipation | (0.25 W + 0.2 W x No of outputs at state 1) |
| Electrical durability | 1000000 cycles DC-12 24 W 24 V resistive | 1000000 cycles DC-3 24 W 24 V inductive | 2000000 cycles DC-3 10 W 24 V inductive | 300000 cycles DC-12 40 W 24 V resistive | 100000 cycles AC-14 220 VA 220 V inductive | 100000 cycles AC-15 220 VA 220 V inductive | 1000000 cycles AC-12 110 VA 110 V resistive | 1000000 cycles AC-12 220 VA 220 V resistive | 1000000 cycles AC-12 50 VA 48 V resistive | 1000000 cycles AC-14 110 VA 220 V inductive | 1000000 cycles AC-15 110 VA 220 V inductive | 150000 cycles AC-14 110 VA 110 V inductive | 150000 cycles AC-15 110 VA 110 V inductive | 1500000 cycles AC-14 50 VA 110 V inductive | 1500000 cycles AC-15 50 VA 110 V inductive | 2000000 cycles AC-14 24 VA 48 V inductive | 2000000 cycles AC-15 24 VA 48 V inductive | 3000000 cycles AC-14 50 VA 220 V inductive | 3000000 cycles AC-15 50 VA 220 V inductive | 500000 cycles AC-12 110 VA 48 V resistive | 500000 cycles AC-12 220 VA 110 V resistive | 500000 cycles AC-14 24 VA 24 V inductive | 500000 cycles AC-15 24 VA 24 V inductive | 5000000 cycles AC-14 10 VA 110 V inductive | 5000000 cycles AC-14 10 VA 220 V inductive | 5000000 cycles AC-14 10 VA 48 V inductive | 5000000 cycles AC-15 10 VA 110 V inductive | 5000000 cycles AC-15 10 VA 220 V inductive | 5000000 cycles AC-15 10 VA 48 V inductive | 700000 cycles AC-12 50 VA 24 V resistive |
| Marking | CE |
| Electrical connection | Screw terminal block |
| Current consumption | 55 mA at 5 V DC | 70 mA at 24 V DC rack |
| Module format | Standard |
| Net weight | 0.33 kg |
| Dielectric strength | 2000 V 50/60 Hz 60 s |
| Standards | UL 508 | 73/23/EEC | 89/336/EEC | CSA C22.2 No 213 Class I Division 2 Group B | CSA C22.2 No 213 Class I Division 2 Group C | IEC 61131-2 | CSA C22.2 No 213 Class I Division 2 Group A | 92/31/EEC | CSA C22.2 No 213 Class I Division 2 Group D | CSA C22.2 No 142 | 93/68/EEC |
| Product certifications | BV | GL | ABS | DNV | RINA | LR | RMRS |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation | 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.5 cm |
| Package 1 Width | 18.0 cm |
| Package 1 Length | 26.0 cm |
| Package 1 Weight | 554.0 g |
