Schneider Electric TSXAEZ802
The Schneider Electric TSXAEZ802 is an analog input module that offers 8 channels for input. It operates with a standard input type of 4 to 20 mA and features a 12-bit analog-to-digital conversion capability.
This Schneider Electric TSXAEZ802 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input range and is referenced internally as PartLogic SKU PL26805317219.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Line | Modicon |
| Part Number | TSXAEZ802 |
| EAN | 3389110604504 |
| Weight | 0.50 lbs (0.23 kg) |
| Product | Analog Input Module |
| Number of Channels | 8 |
| Analog Input Type | 4 to 20 mA |
| Analog/Digital Conversion | 12 bits |
| Acquisition Period | 32 ms |
| Temperature Drift | 0.054%/10 degrees Celsius |
| Input Impedance | 250 Ohm |
| Current Consumption | 60 mA |
| Isolation Voltage | 1000 V |
| Voltage Type | AC |
| Operating Humidity | Up to 80% (non-condensing) |
| Storage Humidity | Up to 80% (non-condensing) |
| Maximum Operating Altitude | 1000 meters above sea level |
| Brand | Schneider Electric |
