Schneider Electric TSXAEY1614
The TSXAEY1614, part of Schneider Electric's TSX Micro PLC series, features 16 analog input channels, allowing for precise thermocouple and voltage measurements. With a conversion resolution of 16 bits, the module effectively monitors a variety of input types, supporting multiple thermocouple standards alongside voltage inputs, ensuring versatile application capability.
This Schneider Electric TSXAEY1614 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input range and is referenced internally as PartLogic SKU PL26904302918.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Premium Automation platform |
| Product or component type | Analog input module |
| Analogue input number | 16 |
| Analogue input type | Thermocouple thermocouple B | Thermocouple thermocouple E | Thermocouple thermocouple J | Thermocouple thermocouple K | Thermocouple thermocouple L | Thermocouple thermocouple N | Thermocouple thermocouple R | Thermocouple thermocouple S | Thermocouple thermocouple T | Thermocouple thermocouple U | Voltage +/- 80 mV |
| Analog/digital conversion | 16 bits |
| Nominal read cycle time | 70 ms per channel |
| Measurement error | 0.8 °C thermocouple E 25 °C | 0.9 °C thermocouple J 25 °C | 0.9 °C thermocouple L 25 °C | 1 °C thermocouple K 25 °C | 1 °C thermocouple T 25 °C | 1 °C thermocouple U 25 °C | 1.1 °C thermocouple N 25 °C | 1.2 °C thermocouple E 0...60 °C | 1.3 °C thermocouple T 0...60 °C | 1.3 °C thermocouple U 0...60 °C | 1.4 °C thermocouple J 0...60 °C | 1.4 °C thermocouple L 0...60 °C | 1.6 °C thermocouple K 0...60 °C | 1.7 °C thermocouple N 0...60 °C | 2.1 °C thermocouple R 25 °C | 2.2 °C thermocouple S 25 °C | 2.4 °C thermocouple R 0...60 °C | 2.5 °C thermocouple B 25 °C | 3.7 °C thermocouple S 0...60 °C | 4 °C thermocouple B 0...60 °C |
| Isolation between channels and bus | 1000 Vrms |
| Isolation between channels and ground | 1000 Vrms |
| Common mode between channels | 250 V AC or 280 V AC |
| Common mode between channels and earth | 250 V DC |
| Input overvoltage protection | -15…15 V at state 0 250 Ohm | -30…30 V at state 1 250 Ohm |
| Electrical connection | 2 connectors SUB-D 25 |
| Overcurrent | -30…30 mA at state 1 250 kOhm |
| Marking | CE |
| Current consumption | 300 mA at 5 V DC |
| Module format | Standard |
| Net weight | 0.35 kg |
| Standards | NFC 42-330 | IEC 1131 | DIN 43710 | IEC 751 | DIN 43760 | IEC 584 |
| Product certifications | DNV | RMRS | LR | ABS | RINA | BV | GL |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation | 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.5 cm |
| Package 1 Width | 18.0 cm |
| Package 1 Length | 26.0 cm |
| Package 1 Weight | 447.0 g |
