Schneider Electric TMASD1
Flash memory card, sd card, 256 mb, memory card for modicon m221, m241 and m251 logic controller
This Schneider Electric TMASD1 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Accessories range and is referenced internally as PartLogic SKU PL26805538265.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon M221 | Modicon M251 | Modicon M241 |
| Accessory / separate part type | SD card |
| Product compatibility | Logic controller |
| Range compatibility | Modicon M241 | Modicon M221 | Modicon M251 |
| Memory type | Flash |
| Memory capacity | 256 MB |
| Accessory / separate part category | Separate parts |
| Product specific application | Program transfer | Application backup |
| MTBF reliability | 3000000 H |
| Data retention time | 10 year(s) at 25 °C |
| Number of read/write cycles | 100000 |
| Net weight | 0.004 kg |
| Ambient air temperature for operation | -10…70 °C |
| Ambient air temperature for storage | -25…85 °C |
| Resistance to electrostatic discharge | 15 kV in air conforming to IEC 61000-4-2 | 4 kV on contact conforming to IEC 61000-4-2 |
| Vibration resistance | 1 gn conforming to IEC 61131-2 2007 |
| Shock resistance | 15 gn conforming to IEC 61131-2 2007 |
| Relative humidity | 0…95 % without condensation |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.000 cm |
| Package 1 Width | 12.000 cm |
| Package 1 Length | 14.500 cm |
| Package 1 Weight | 25.000 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 50 |
| Package 2 Height | 15.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 1.566 kg |
