Schneider Electric SSRPP8S50A1
Solid state relay panel mount 280VAC 50A
This Schneider Electric SSRPP8S50A1 is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Solid state relays range and is referenced internally as PartLogic SKU PL26899023875.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Zelio Relay |
| Product or component type | Solid state relay |
| Device short name | SSR |
| Network number of phases | 1 phase |
| Mounting support | Panel |
| [In] rated current | 50 A |
| Output voltage | 24...280 V AC |
| [Uc] control circuit voltage | 90...280 V AC |
| Contacts type and composition | 1 NO |
| Tightening torque | <= 1.1 N.m for input | <= 2.2 N.m for output |
| Local signalling | LED (green) for input status |
| Switching voltage | 90 V AC turn-on | 10 V AC turn-off |
| Input current limits | 6 mA |
| Solid state output type | Zero voltage switching | SCR output |
| Load current | 0.15…50 A |
| output sustained overvoltage | 600 V |
| Surge current | 625 A for 16.6 ms |
| Maximum voltage drop | <1.6 V on-state |
| thermal resistance | 0.63 °C/W |
| Maximum I²t for fusing | 1620 A².s for 8.3 ms |
| Maximum leakage current | 10 mA off-state |
| DV/dt | 500 V/µs off-state at maximum voltage |
| Response time | 0.5 cycle (turn-on) | 0.5 cycle (turn-off) |
| Standards | IEC 60950-1 | IEC 62314 | UL E258297 | CSA LR 40487 |
| Marking | CE |
| IP degree of protection | IP20 |
| Ambient air temperature for operation | -40…80 °C |
| Ambient air temperature for storage | -40…125 °C |
