Schneider Electric LV429488
Earth-leakage add-on protection module vigipact, compact nsx 100,160, 200VAC to 440VAC, 30mA to 30A, 3 poles
This Schneider Electric LV429488 is supplied brand new by PartLogic for control panels, machine wiring, power distribution, industrial maintenance and replacement applications. It forms part of our Industrial automation > Electrical distribution > Circuit breakers range and is referenced internally as PartLogic SKU PL26805558894.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | ComPacT NSX100...250 | ComPact NSX100...250 |
| Device short name | VigiPacT |
| Product or component type | Vigi add-on |
| Device application | Wiring |
| Range compatibility | ComPacT ComPacT NSX100 circuit breaker | ComPacT ComPacT NSX160 circuit breaker | ComPact ComPact NSX100 circuit breaker | ComPact ComPact NSX160 circuit breaker |
| Poles description | 3P |
| [In] rated current | 100 A | 160 A |
| Earth-leakage protection class | Class A | Class AC |
| Residual earth-leakage sensitity adjustment type | Adjustable |
| Earth-leakage sensitivity | 0.03 A for class A | 0.1 A for class A | 0.3 A for class A | 0.5 A for class A | 1 A for class A | 3 A for class A | 10 A for class AC | 30 A for class AC |
| Residual earth-leakage time delay adjustment type | Adjustable |
| [Δt] residual earth-leakage time delay adjustment | 0 ms | 60 ms | 150 ms | 300 ms | 500 ms | 800 ms | 1.2 s | 4 s |
| Network type | AC |
| Network frequency | 50/60 Hz |
| [Ue] rated operational voltage | 200...440 V AC 50/60 Hz conforming to IEC 60947-2 |
| Earth-leakage protection | With |
| Maximum breaking time | 800 ms |
| Overvoltage category | IV |
| Electrical shock protection class | Class II |
| Standards | IEC 60947-2 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 13.000 cm |
| Package 1 Width | 14.500 cm |
| Package 1 Length | 17.000 cm |
| Package 1 Weight | 1.083 kg |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 40.000 cm |
| Package 2 Length | 60.000 cm |
| Package 2 Weight | 13.440 kg |
| Unit Type of Package 3 | P12 |
| Number of Units in Package 3 | 48 |
| Package 3 Height | 42.000 cm |
| Package 3 Width | 80.000 cm |
| Package 3 Length | 120.000 cm |
| Package 3 Weight | 65.984 kg |
