Schneider Electric LC1F265G7
The Schneider Electric LC1F265G7 is a highly capable contactor designed to manage significant electrical loads. With a robust current capacity of 265 A, this device is suitable for high-power applications.
This Schneider Electric LC1F265G7 is supplied brand new by PartLogic for switching, motor protection, starting, control panel builds, machinery maintenance and industrial electrical applications. It forms part of our Industrial automation > Motor control > Contactors range and is referenced internally as PartLogic SKU PL26805664410.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Type | Contactor |
| Product Line | TeSys |
| Part Number | LC1F265G7 |
| EAN | 3389110351613 |
| Weight | 17.00 lbs (7.71 kg) |
| Current | 265 A |
| Power | 132 kW @ 400 V |
| Temperature Range | -5 to 55 °C |
| Voltage | 600 V AC |
| Mounting | DIN/Panel |
| Cycles per Hour | Up to 2400 |
| Certifications | IEC, UL, CSA |
| Number of Poles | 3 (3NO) |
| Terminals | Box clamp |
| Enclosure | Open |
| Compliance | RoHS, REACh |
| Control Voltage | 120 V AC |
| Brand | Schneider Electric |
